introducing low cost, multi camera, live production with advanced broadcast features
rgblink mini switchers make it easy to create professional multi camera or hdmi content productions for live streaming to youtube and innovative business presentations using zoom or cloud conference! simply connect rgblink mini and you can switch live up to 4 high quality video camera inputs for dramatically charming quality images. or connect multi ptz camera for training or conference with ptz consoles built in. there are lots of seamless video transition effects for switching between any two inputs, also for picture in picture effects! all rgblink mini models have usb that works like a webcam so you can use any streaming software. rgblink mini even has secret broadcast features for high end work!
mini is a “mini” signal switcher and mixer which is able stream 6picture pvw or pgm from any one out of the 4 hdmi inputs to any live broadcasting platform via third party live streaming software such as obs. it adopts compact design, equipped with a 2 inch tft screen to preview the 4 inputs in real time. 14 transition effects on board to collaborate with tbar to do transition switching. along with feature of seamless switch, there are other outstanding features such as audio embedding, deembedding, and automatically identifying color depth of rgb4:4:4, yuv4:4:4, yuv4:2:2,yuv4:2:0. mini is based on mini but with advanced features including chroma key, logo, ptz camera control. it is also easy to operate either on board or on dedicated app xpose on pc.
mini is a “mini” signal switcher and mixer which is able stream 6picture pvw or pgm from any one out of the 4 hdmi inputs to any live broadcasting platform via third party live streaming software such as obs. it adopts compact design, equipped with a 2 inch tft screen to preview the 4 inputs in real time. 14 transition effects on board to collaborate with tbar to do transition switching. along with feature of seamless switch, there are other outstanding features such as audio embedding, deembedding, and automatically identifying color depth of rgb4:4:4, yuv4:4:4, yuv4:2:2,yuv4:2:0. mini is based on mini but with advanced features including chroma key, logo, ptz camera control. it is also easy to operate either on board or on dedicated app xpose on pc.
mini makes the sophisticated simple. switch seamlessly between any of the four hdmi inputs and output to both hdmi and the dedicated usb 3.0 output. mini is equally ideal for live streaming applications and presentations, allowing multiple sources to be utilized for a a professional impression every time. on board features include pip, transition effects and external audio embedding, and with the mini feature pack there is support for sony visca ptz cameras and dsk. large buttons make quick actions easy, while the provision of the t-bar allows smooth transition between sources, whether they be cameras or graphics. compact in size, mini goes anywhere, and with handy features like the ability to mount to standard 1/4in unc accessories, mini is at home in any studio.
easy to use
and fast to learn!
there's never been a switcher that’s easier to use, as you simply press any of the input buttons labelled by number on the front panel to cut between video sources, especially all the 4 inputs preview directly on its 2 inch tft display for switching decision. you can choose between cut or effects transitions by selecting in the menu. unlike cut, the other transition tells rgblink mini to use a video effect when switching inputs. you can select from exciting transitions such as dissolve. picture in picture transition effects is available between preview and program too.
stream live training in studio
rgblink mini is perfect for training / education as you can connect at least one cameras and one hdmi content source for the trainer to be interactive with the content, to sell out the trainer idea to the watcher much effective, it just need to set up a simple training / education virtual studio!
cook show and business presentations
livestreaming with more engage
cook show shares how to make a delicious food as vlog, and the live business presentations on skype because rgblink mini makes skype see it as a webcam, so you can select it in the skype settings! one camera can be a close up, another for a wide shot and a computer for powerpoint presentations. the presenter can even use picture in picture!
the social influencer's marketing activity makes the salels growing sharply. rgblink mini supports ptz camera control, which makes the influencer to show the goods into the detail much better. the influencer can even use picture in picture, and have the presentation with better result.
education and training
live stream esport competitions
rgblink mini is perfect for educational videos! setup is fast and easy, so you can travel to locations and record live multi camera video productions on a wide range of educational topics! connect computers and cameras and use the xpose software to load logo and perform video effects. rgblink mini also supports ptz camera to set position presets and go to the right position in need.
live stream esport competitions to twitch by simply connecting multiple gaming consoles and a camera for a presenter. rgblink mini operates up to 60 frames per second for fast gameplay and you can use picture in picture for commentary! rgblink mini uses h.265 codec and make sure the most less frame delay.
outputs to hdmi display and
usb webcam!
to ensure maximum compatibility, all rgblink mini models feature usb that operates as a simple webcam source. that means you can plug into a computer and get working with any video software! the software is tricked into thinking the rgblink mini is a common webcam, but it's really a live production switcher. that guarantees full compatibility with any video software and in full resolution 1080hd quality. choose any software you like, such as zoom, microsoft teams or skype for a new way to do presentations with a professional multi camera broadcast quality style! the rgblink mini webcam output also works with streaming software such as open broadcaster, xsplit broadcaster and more!
build in 4 inputs multiviewer with
2 inch tft display
rgblink mini is the 1st compact and lower budget livestreaming switcher with onboard built in multiviewer on its 2 inch tft display. it saves the cost for the operator to connect an external hdmi display to preview the inputs. it makes the livestreaming or conference meeting system much simple and afortable.
chroma key makes virtual studio
much easier
for chroma key application, how to pick up the “green” pixels are very important for the traditional chroma key application, and which “green” pixels will decide the chroma key quality. it makes the operator to setup with the software and also need to take time to try to find the best quality. rgblink mini makes this much simple, user just need to decide which kind of background to be used with chroma key, such as “green” or “blue”, don’t need to pick up the pixels from this background, just adjust two parameters and can get chroma key done in a minute. rgblink mini also shows much better image quality in higher brightness content over the background. rgblink mini opens an easy operation window for all the content maker and makes the interactive between content and the operator wide potential.
add exciting video effects
one of the benefits of rgblink mini is the professional production values that are possible using the range of built in video effects! the cut transition ensures an instant cut when switching between sources. the other transitions are a professional term that's used on large broadcast switchers to enable video effect transitions. there are duration buttons for video effects allowing 0.5, 1, 1.5 and 2 second settings. you can also select the type of effect you want including mix, which does a smooth transition between sources, and picture in picture preset transition with program!
work with professional microphones
with an independent 3.5mm stereo audio inputs, you can connect desktop or lapel microphones (mic in version need an external msp232 converter). you can even connect a music player to generate introduction music after the live stream commences but before the program starts. with the extra stereo audio inputs, you can ensure a separate audio to embed into the original signal by replace the audio in the signal in need. all audio inputs to rgblink mini include buttons on the panel for adjusting audio level and enabling inputs into the audio mixer.
automatically converts
any hdmi input format
each of the hdmi inputs feature their own dedicated standards converter. that means rgblink mini will automatically convert 1080p, 1080i and 720p sources to the switcher video standard! by default the switcher will set its video format automatically, however you can also set the switcher to any video standard! the hdmi outputs are a true "aux" output so you can clean switch each hdmi input to the output., the hdmi output can be selected to display a full multiview! rgblink mini even supports different input standards for each input at the same time, which makes the different signal connection much easier and cost lower.
includes free xpose software control panel
the xpose software control app unlocks the hidden power of rgblink mini and allows access to every feature in the switcher. xpose software control features a visual switcher user interface with parameter palettes for making quick adjustments. you can normally connect via ethernet, and it's possible for multiple users to connect to rgblink mini using separate copies of xpose software control on different computers! the software lets you access full chroma key effects, load still frames and ptz programming! you can even run xpose on ios and android mobile device.
dve for picture in picture, transitions and effects
one of the most exciting features on rgblink mini is the digital video effects processor, commonly referred to as a "dve", that allows picture in picture effects and crazy dve transitions! the dve lets you create professional picture in picture effects. the image quality is the same as high end rgblink m series switcher models and the dve supports position, resize and scale for picture in picture, and make the transition between preset and program, all in real time. the dve can also be used to create amazing transitions with 13 different dve squeeze and dve push effects for adding excitement to your programming.
build in logo overlay
includes new mini advanced chroma key
for news or on-set presentation work, rgblink mini is perfect as it features the powerful advanced chroma key for green screen keying effects. the chroma keyer is incredibly powerful and does need a color picker to sample background colors, but it automatic generation of the key parameters. you get precise controls for edge and flare, and there is even a foreground color corrector so you can match the foreground and background layers for seamless compositions. you can even use it for title overlays by creating graphics with a green or blue background. rgblink mini chroma key makes the virtual studio setup and application the most easiest in the world!
with xpose app, the logo to be overlay on the source can be download to rgblink mini, and operator can decide the position of the logo on the top of the signal. it makes the title visible and help with the notes too.
true broadcast style mix effects switching
although rgblink mini works in "cut bus" mode when first purchased, it can also be changed to "program/preview" style operation, which is the way large broadcasters use live production switchers. cut bus switching is easy and selecting any input will instantly switch to that source. however if you want to operate rgblink mini like a true professional then you can change the switcher to program/preview using xpose software control. mix effects operation allows a source to be selected and ready to be put on air until you move the t-bar. that 2 step program/preview process means fewer mistakes. program/preview operation is best for training students for a career in broadcast!
built in preview on a 2 inch tft display
rgblink mini provides a quarter 2x2 preview for the inputs with its onboard 2 inch tft display directly, save the cost by do not need to connect to an external monitor. all the inputs, even they are all in different standard, can be previewed on this display directly.
monitor sources and status with rgblink mini multiview!
when doing larger live productions with multiple cameras, it’s very useful to see all your video sources at the same time on a single monitor. the rgblink mini provides a professional multiview on its dedicated hdmi output or its usb output that lets you see all video inputs, preview and program on a single hdmi television or monitor! each camera view includes audio meters.
develop custom remote
control solutions
the ethernet connection also allows the 3rd party control solutions! even though rgblink mini includes xpose software control, you can use the ethernet to control the mini remotely, anywhere in the world. rgblink provides an open api for this kind of application. open api is available based on request!
